Introducing KYOCERA AVX’s New BP1206 & BP2816 Series Thin-Film Band-Pass Filters

Amar Radio Corporation is excited to announce the launch of KYOCERA AVX’s latest innovation in RF filtering technology – the BP1206 and BP2816 Series Thin-Film Band-Pass Filters. These compact, high-performance filters are engineered to provide exceptional RF performance for a wide range of high-frequency wireless applications in the telecommunications, military, aerospace, medical, and consumer electronics industries.

Cutting-Edge RF Performance for High-Power Applications

The BP1206 and BP2816 Series leverage KYOCERA AVX’s proven multilayer integrated thin-film (ITF) technology, ensuring:

• Highly repeatable and reliable RF performance
• Low insertion loss and steep attenuation
• Sharp roll-off and low noise
• High temperature stability

These features make them an ideal choice for crowded PCBs where performance and space efficiency are critical.

Robust Design & Versatile Applications

Both series are constructed with a rugged, compact, low-profile case, featuring lead-free, solder-coated-nickel land grid array (LGA) terminations for seamless integration with automated assembly processes like reflow, wave, and vapor phase soldering.

With 8W continuous power handling and 50Ω characteristic impedance, these filters support a variety of frequency bands ranging from 240MHz to 6,100MHz, meeting the demands of modern high-frequency wireless systems.

Product Highlights

BP1206 Series

• Miniature 1206 case (3.10mm x 1.60mm x 0.60mm)
• Supports frequencies from 1,250MHz to 6,100MHz
• Out-of-band rejection: -25 to -40dB
• Ideal for:
  • 5G and 6G LTE networks
  • Base stations
  • Antenna matching
  • Satellite communications

BP2816 Series

• Compact 2816 case (7.2mm x 4.2mm x 1.2mm max)
• Supports frequencies from 240MHz to 1,260MHz
• Out-of-band rejection: -20 to -45dB
• Ideal for:
  • MRI machines
  • Wireless communications
  • Military and handheld radios

Quality & Compliance

KYOCERA AVX ensures the highest level of quality by manufacturing these filters in ISO-9001 facilities, with each unit 100% tested for electrical parameters, visual and mechanical characteristics. They also comply with RoHS and IATF 16949 standards, ensuring high reliability and consistency across production lots.

Final Thoughts

The BP1206 and BP2816 Series Thin-Film Band-Pass Filters represent a significant advancement in RF filtering technology, offering superior performance in a smaller, more rugged package than competing solutions. Their versatility across multiple industries makes them an excellent choice for engineers and designers looking to optimize RF performance in their applications.

At Amar Radio Corporation, we take pride in offering the latest and most innovative electronic components. Stay tuned for availability updates and contact us for more details on how these KYOCERA AVX filters can enhance your next project!
